執筆バージョン: Unreal Engine 5.0
|
Niagara の「Shape Location」モジュールを使用すると、特定の形状(球や正方形など)に沿わせてパーティクルを発生させる事ができます。
パラメータの設定次第で色々な形状にする事ができるので、今回は実例とセットでパラメータの紹介をしていきたいと思います。

【事前準備】
まずは「Particle Spawn」右側の「+」を押下し、「Shape Location」を選択し、モジュールを追加してください。

今回ベースにした Emitter は「Fountain」で、パーティクルの発生位置をわかりやすくするために、下記のモジュールは無効にしています
- Add Velocity
- Gravity Force
- Drag
- Solve Forces and Velocity
Sphere(球状)

Clylinder(円柱状)

画像 |
内容 |
パラメータ |
 |
円柱の表面に沿ってパーティクルを発生させる
|
- Shape Primitive = Cylinder
- Surface Only Band Thickness = 0.0
- Cylinder Distribution = Random
|
 |
かまぼこ状にパーティクルを発生させる
|
- Shape Primitive = Cylinder
- Surface Only Band Thickness = 0.0
- Cylinder Distribution = Random
- Hemicircle X = True
- Hemicircle Y = False
- Rotation Axix = X:-1.0 , Y:0.0 , Z:0.0
|
 |
カーブに沿わせて円柱の側面の形状を変形させる
|
- Shape Primitive = Cylinder
- Cylinder Distribution = Random
- Enable Lathe Profile = True

|
Box/Plane(箱状、板状)

画像 |
内容 |
パラメータ |
 |
箱の表面に沿ってパーティクルを発生させる
|
- Shape Primitive = Box/Plane
- Box/Plane Mode = Box
- Serface Only Band Thickness = 0.0
- Cylinder Distribution = Random
|
 |
直線上にパーティクルを発生させる
|
- Shape Primitive = Cylinder
- Box/Plane Mode = Plane
- Plane Size = X:0.0 , Y:100
|
Torus(トーラス状)

画像 |
内容 |
パラメータ |
 |
トーラスの表面に沿ってパーティクルを発生させる
|
- Shape Primitive = Trus
- Large Radius = 50
- Handle Radius = 15
- Surface Distribution = 1.0
|
 |
半月型のトーラスの表面に沿ってパーティクルを発生させる
|
- Shape Primitive = Trus
- Large Radius = 50
- Handle Radius = 15
- Surface Distribution = 1.0
- U Distribution = 0.5
- V Distribution = 0.0
|
 |
底の抜けたお椀状にパーティクルを発生させる
|
- Shape Primitive = Trus
- Large Radius = 40
- Handle Radius = 30
- Surface Distribution = 1.0
- U Distribution = 0.0
- V Distribution = 0.75
|
Ring/Disk(リング状/ディスク状)

画像 |
内容 |
パラメータ |
 |
六角形状にパーティクルを発生させる
|
- Shape Primitive = Ring/Disc
- Ring/Disc Mode = Hexagon
|
 |
円盤状にパーティクルを発生させる
|
- Shape Primitive = Ring/Disc
- Ring/Disc Mode = Circle
- Ring/Disc Distribution Mode = Random
- Disc Coverage = 1
|
 |
半月状にパーティクルを発生させる
|
- Shape Primitive = Ring/Disc
- Ring/Disc Mode = Circle
- Ring/Disc Distribution Mode = Random
- Disc Coverage = 1
- U Distribution = 0.5
|
 |
渦巻状にパーティクルを発生させる
|
- Shape Primitive = Ring/Disc
- Ring/Disc Mode = Circle
- Ring/Disc Distribution Mode = Uniform
- Uniform Spiral Amount = 0.1
- Uniform Spiral Falloff = 1
|
Cone(円錐状)

画像 |
内容 |
パラメータ |
 |
円錐状の表面に沿ってパーティクルを発生させる
|
- Shape Primitive = Cone
- Ring/Disc Mode = Spherical Cone
- Cone Length = 100
- Cone Angle = 50
- Cone Inner Angle = 50
|
 |
楔型(≒四角錐型)にパーティクルを発生させる
|
- Shape Primitive = Cone
- Ring/Disc Mode = Spherical Wedge
|
 |
底の抜けたカップ状にパーティクルを発生させる
|
- Shape Primitive = Ring/Disc
- Ring/Disc Mode = Circle
- Ring/Disc Distribution Mode = Random
- Disc Coverage = 1
- Cone Surface Distribution = 0.5
|
